Revv 1

Powerful moto-inspired moped ebike

-

-

Speed

Speed

20+ MPH* on throttle & pedal assist. Additional class modes & speeds.

Motor

Motor

Powerful 750w sustained geared hub motor with 90nm torque

Range

Range

30-60 miles depending on battery, rider weight, terrain, incline, level of assist, etc.

Frame

Frame

Durable Alloy Frame with internal protected & locked electronics

Comfort

Comfort

Frame geometry & components built for a comfortable upright position

MULTI-CLASS SPEED SYSTEM

The Revv 1 ships pre-programmed as a class 2 (pedelec) ebike which enables speeds of up to 20 MPH on pedal assist and throttle. The multi-class speed system gives riders access to configure the setting and switch to 'Off-Road' mode which unlocks speeds of 28+ MPH for private use only. Learn more.

https://ride1up.com/wp-content/uploads/2022/05/ride1up-serviceandsupport.png

Service & Support

Seasoned Bike Mechanics Offer Expert Technical Support and Friendly Customer Service.

Learn More

https://ride1up.com/wp-content/uploads/2022/05/ride1up-1yearwarranty.png

1-Year Warranty*

Every Ride1UP eBike Comes With a Warranty Against Manufacturing Defects. *Terms Apply

Learn More

https://ride1up.com/wp-content/uploads/2022/05/ride1up-freeshipping.png

Free Shipping

On All Bikes to Contiguous 48 States. $400 Direct Shipping to Canada. Exclusions Apply.

Learn More

COMPONENTS

Motor
Motor
52V Geared Hub Bafang Motor 750w
Motor
Controller FS
52V 28A 18 Mosfets
Motor
Controller HT
52V 25A 12 Mosfets
Motor
Battery FS
52V 20ah, Samsung 50E 21700 Cells (56 cells)
Motor
Battery HT
52V 15ah, Samsung 50E 21700 Cells (42 cells)
Motor
Display
3.5" Center Mount w/ Watt 'RPM' bar and turn signal indicators
Motor
PAS Sensor
Integrated Sensitive Cadence Sensor
Motor
Brakes
4-piston Hydraulic Disc Brakes w/ Electric Cut-Off Sensor
Motor
FS Fork
Double-crown 120mm Air Fork, Preload and Rebound adjust w/ hydraulic lockout
Motor
HT Fork
100mm Air Fork, Rebound adjust and hydraulic lockout
Motor
Rear Suspension
DNM AOY-38RC, rebound, air pressure adjust and lock-out
Motor
Throttle
Right-hand Twist Throttle
Motor
Handlebar
Width: 720mm, Sweep: 25°, Rise: 120mm
Motor
Stem
Promax. Height: 45mm, Rise: 6°
Motor
Grips
Anti-slip Rubber Grips
Motor
Chainring and Cranks
32T Chainring w/127mm cranks
Motor
Chain
KMC Pro
Motor
Tires FS
CST Scout eMoped All-surface Tires, 20x4.0"
Motor
Tires HT
Kenda Krusade 20x4.0"
Motor
Tubes
Black Butyl added to prevent flats
Motor
Fenders
Hardened Alloy Fenders
Motor
Front light
Moto Style Round Headlight, 120 LUX, high & low beam
Motor
Rear light
Starunion Brake Light
Motor
Seat
Customized cafe style saddle
Motor
Pedals
Alloy Black Pedals

DIMENSIONS AND SIZING

  • Weight Capacity 400lbs
  • Rider Height Range 5'2" - 6'4"
    • FS Frame Dimensions:
    • Total Weight 93lbs
    • Handlebar Height 40.5”
    • Handlebar Reach 14.75”
    • Seat Height 32.5"
    • Stand-Over Height 32.5”
    • Wheel Base 49"
    • Total Length 72"
    • HT Frame Dimensions:
    • Total Weight 83lbs
    • Handlebar Height 40.5”
    • Handlebar Reach 14.75”
    • Seat Height 32.5”
    • Stand-over Height 32.5"
    • Wheel Base 44”
    • Total Length 69"

WHAT'S INCLUDED

number

Powerful integrated moto-style headlight and brake taillight. FS frame shown includes turn signals.

number

Handlebar-Mounted, Two-Tone LCD Display. Customizable Pedal Assist (PAS) Settings and Advanced Metrics for Intelligent Riding Feedback.

number

All-terrain 20"x4" e-moped fat tires for cruising comfort and advanced cornering traction. High performing and reliable –– perfect for variable terrain.

number

Heavy-duty, adjustable chainstay kickstand. High-load capacity for extra support and stability.

number

52V 4 Amp (FS) charger and cable
52V 3 Amp (HT) charger and cable
LED indicator provides real-time charging status.

number

Two keys for the removable battery system. Theft protection design –– battery anxiety begone!

Shipping Information

The Revv 1 is currently on pre-order. Refer to each respective model for expected shipping times.

The bike will arrive 90% assembled (electronics are pre-assembled). Basic assembly is required.

FAQ'S

We are a direct-to-consumer electric bike company both in pricing and strategy. You will generally pay a premium for the ability to test ride an electric bike through a dealer. However, our electric bikes have been thoroughly tested by top reviewers such as Electric Bike Review, Electric Bike Report, Cycling Weekly, Clean Technica, Electrek, and many others who have published their reviews on YouTube. You can read electric bike reviews on any of those sites. Additionally, we are now supporting an independent network of owners offering their bikes for demos. Learn more about e-bike demos here Locations

This article will explain all about what to expect when ordering an electric bike from us. Ordering With Us

If you purchase the Hardtail (HT) frame type, which comes with a 15ah battery, you can purchase the 20ah battery if it is in stock as an add-on. We cannot replace the 15ah battery with the 20ah battery before shipping out the hardtail bike.

No, you cannot switch the handlebars on the Revv1. The variations you see on the site are the only options we have for our electric bike models.

We only ship our electric bikes within North America. The Continental United States is FREE. Shipping to Hawaii is $600 and shipping to Canada is $400. We are not responsible for any additional tariffs charged by your local government which often times applied after importing ebikes. Unfortunately, we are not able to ship our electric bikes directly to Europe or Alaska at this time. You can use a shipping forwarder like ShopUsa.com to reach your country.

The electric bikes are not water-proof, they are water-resistant, rated IP-65. While we do not recommend leaving the bikes out in the rain or riding in the rain or other hazardous conditions due to personal safety, our electric bikes can handle water exposure. Leaving your ebike in the rain or other hazardous conditions could shorten the lifespan of the electric bike.
