LMT’D V2

In Stock

Powerful torque-sensing ebike

213 reviews
Frame Type ST
ST - Step-Through
XR - Step-Over

-

Is this the right bike for me? Let's chat: 1-877-RIDE1UP
Pre-sale support hours

9:00 AM - 5:00 PM PST

Monday - Friday

8AM-12PM PST - Saturday

-

LMT’D V2 At A Glance

Speed

Speed

Class 3 electric bike, with 28mph pedal assist and 20mph throttle

Motor

Motor

Powerful 750w sustained angled-gear hub motor. Learn more.

Range

Range

30-50 miles depending on rider weight, terrain, incline, level of assist, etc.

Frame

Frame

Lightweight Alloy Frame with internal protected & locked electronics

Comfort

Comfort

Frame geometry & components built for "the most comfortable ride ever"

Features & Highlights

whats-photo
Integrated torque sensor providing a more responsive, and intuitive riding experience. Gives riders improved efficiency and control with each pedal stroke.
whats-photo
SR Suntour XCM32 ATB front suspension fork with 100mm travel, hydraulic lockout and adjustable preload settings for added comfort and performance.
whats-photo
Programmable handlebar-mounted color display
whats-photo
High performing all-terrain WTB Groov-e 27.5" x 2.4" tires. Features durable wire bead to provide stability and water-channeling grooves to provide reliable traction in all weather conditions.
whats-photo
Hardened alloy front and rear fenders
whats-photo
Front light and fender integrated rear light
whats-photo
48V two-amp charger and cable
whats-photo
Two Keys for the removable frame-integrated battery
whats-photo
Heavy-duty, adjustable chainstay-mounted kickstand

Components & Tech Specs

minus plus
Motor
Motor
48V Angled Gear Hub AKM Motor 750w Sustained
Motor
Battery
48V 14Ah Reention Prism LG Cells, Smart BMS. UL 2271 Certified
Motor
Display
KD218 adjustable speed color display
Motor
PAS Sensor
Integrated sensitive torque sensor. Learn more about
Torque vs. Cadence Sensors
Motor
Brakes
Tektro HD-M285 180mm hydraulic
Motor
Fork
SR Suntour XCM32 ATB 100mm travel coil suspension fork with adjustable preload and hydraulic lockout
Motor
Throttle
Left side thumb throttle
Motor
XR Handlebars
31.8mm riser bars, 50mm rise
Motor
ST Handlebars
31.8mm City/cafe upright handlebars
Motor
Controller
48V 20A Lishui Sine-wave
Motor
Grips
Ergonomic locking rubber grips
Motor
Shifters
Shimano 8-speed rapidfire plus
Motor
Gearing
48T alloy chainring with 170mm crank arms
Motor
Cassette
Shimano CS-HG200-8, 8-speed
Motor
Derailleur
Shimano RD-M370
Motor
Chain
KMC Z8.3 8-speed chain
Motor
Spokes
Black stainless steel, 13G
Motor
Saddle
Velo comfort gel
Motor
Seat Post
350mm x 31.6mm Dual Bolt
Motor
Stem
Promax 28.6mm, 45mm ext. 31.8mm bar clamp
Motor
Rack
Available as accessory purchase
Motor
Front Light
60 lux front light
Motor
Rear Light
Fender integrated rear light
Motor
Fenders
Hardened metal alloy
Motor
Additional
Water bottle bosses and chainstay guard

Dimensions & Sizing

minus plus
dim-img
ST
XR
Bike Weight
Weight Capacity
Rider Height Range
A - Maximum Seat Height
B - Minimum Seat Height
C - Stand-over Height
D - Wheelbase
E - Top Tube Length
F - Head Tube Length
G - Seat Tube Length
H - Chainstay Length
I - Fork Length
J - Head Tube Angle
K - seat Tube Angle
L - Stack
M - Handlebar Reach
N - Total Length
O - Handlebar Height
55 lbs
300lbs
5'1"-6'2"
1080mm 43in
813mm 32in
584mm 23in
1100mm 43in
559mm 22in
165mm 6in
457mm 18in
460mm 18in
502mm 20in
69°
72°
670mm 26in
365mm 14in
1816mm 71in
1130mm 44in
55lbs
300lbs
5'6"-6'4"
1080mm 43in
813mm 32in
762mm 30in
1100mm 43in
559mm 22in
165mm 6in
457mm 18in
460mm 18in
502mm 20in
69°
72°
670mm 26in
365mm 14in
1816mm 71in
1092mm 43in
CONVERT MEASUREMENTS

Assembly & Support

minus plus

Bike Will Arrive 85% Assembled (electronics are pre-assembled). Basic Assembly Steps Are Required As Noted In The Video Above.

Bikes In Stock Ship In Under 24 Hours. Email Tracking Provides Transit And Delivery Estimates Once Shipped. Package Size is 53″x27″x10″ and just under 65lbs.

FAQ'S

minus plus
What is the difference between the LMT'D and the LMT'D V2? minus plus

The LMT’D V2 comes with updated frame geometry, increased travel front suspension, stock fenders, fender integrated brake light, and an upgraded motor utilizing angled gears for a quiet and smooth ride experience. To get a more in-depth breakdown of the differences and improvements view our launch blog of the LMT’D V2.

Can I test ride a bike? minus plus

We are a direct-to-consumer company both in pricing and strategy. You will generally pay a premium for the ability to test ride through a dealer. However, our bikes have been thoroughly tested by top reviewers such as Electric Bike Review, Electric Bike Report, Cycling Weekly, Clean Technica, Electrek and many others who have published their reviews on YouTube. Additionally, we are now supporting an independent network of owners offering their bikes for demos. Learn more here Locations

What can I expect ordering a bike from Ride1Up? minus plus

This article will explain all about what to expect when ordering a bike from us. Ordering With Us

Can I upgrade the battery? minus plus

The 14ah battery pack is the largest available that will fit this frame.

Can I switch the handlebars to another model? minus plus

No. The variations you see on the site are the only options we have.

Can you ship to _______? minus plus

We only ship within the US and Canada. The contiguous United States is FREE. Hawaii and Alaska is $600. Shipping to Canada is $100. We are not responsible for any additional tariffs charged by your local government which often times applied after importing. Unfortunately, we are not able to ship our bikes directly to Europe. You can use a shipping forwarder like ShopUsa.com to reach your country.

Are the bikes water-proof? minus plus

The bikes are not water-proof, they are water-resistant, rated IP-65. While we do not recommend leaving the bikes out in the rain or riding in the rain or other hazardous conditions due to personal safety, the bikes can handle water exposure.
