700 Series

(301 customer reviews)

Configure

STSTXRXR
Gunmetal GrayGunmetal GrayGunmetal GraySteelSteelSteel
Clear
Speed

Speed

Class 3 electric bike, with 28mph pedal assist and 20mph throttle

Motor

Motor

Powerful 800W (peak) 500W (sustained) geared motor with 56nm torque

Range

Range

30-50 miles depending on rider weight, terrain, incline, level of assist, etc.

Frame

Frame

Lightweight Alloy Frame with internal protected & locked electronics

Comfort

Comfort

Frame geometry & components built for "the most comfortable ride ever"

https://ride1up.com/wp-content/uploads/2020/11/s1-1.png

FINANCING
AVAILABLE

0% APR financing available. Make easy monthly payments over 3, 12, or 18 months*

https://ride1up.com/wp-content/uploads/2020/11/s2-1.png

SERVICE
& SUPPORT

Expert technical support and friendly customer service

https://ride1up.com/wp-content/uploads/2020/11/s4-1.png

1-YEAR
WARRANTY

Every bike comes with a warranty against manufacturing defects

https://ride1up.com/wp-content/uploads/2020/11/s3-1.png

30 DAY
TRIAL

If you’re not thrilled, send it back for a full refund

https://ride1up.com/wp-content/uploads/2020/11/s5-1.png

FREE
SHIPPING

On all bikes to contiguous 48 states. $100 to Canada and Mexico

COMPONENTS

Motor
Motor
48V500W Geared Hub Shengyi Motor
Motor
Battery
48V14ah Reention Rhino, 52x Samsung 35E Cells, Smart BMS
Motor
Display
KD218 Adjustable Speed Color Display
Motor
PAS Sensor
Integrated Sensitive Cadence Sensor PAS
Motor
Brakes
Tektro Dual Piston Hydraulic Brakes w/ Electric Cut-Off Sensor
Motor
Fork
Mozo Hydraulic Lockout, 100mm Suspension Travel
Motor
Tires
Schwalbe SUPER MOTO X 27.5x2.4 (584-60) tire
Motor
Throttle
Left side Thumb Throttle
Motor
Handlebar
ST Frame: City/Café Upright Handlebars XR Frame: Riser Bars, 31.8mm Bar, with 25mm Rise
Motor
Controller
48V22A Lishui Sine-wave
Motor
Grips
VELO Faux-Leather Grips
Motor
Shifters
SHIMANO ACERA 8 speed trigger shifter
Motor
Gearing
45T Front Alloy Chainring
Motor
Cassette
11-30T Shimano Cassette
Motor
Derailleur
Shimano Acera RD-M3000
Motor
Chain
KMC Professional 8-Speed Chain
Motor
Rims
3D Double Wall Rim, 33mm Width
Motor
Spokes
Stainless steel, 12G rear, 13G front
Motor
Fenders
Hardened Alloy Fenders
Motor
Rear Rack
50lbs Rated Loading Weight With Pannier Side Mount
Motor
Front light
Blaze-lite Front Light
Motor
Rear light
Spanninga Luceo Rear Light
Motor
Saddle
Selle Royal Freeway Plush Gel
Motor
Seat Post
Promax 31.6mm x 350mm Adjustable Angle
Motor
Brake Cables
Jagwire Brake Cables
Motor
Pedals
Wellgo Alloy Pedals
Motor
XR Stem
PROMAX Adjustable 0-60° 90mm 31.8mm Bar Clamp
Motor
ST Stem
PROMAX Adjustable 0-60° 60mm 31.8mm Bar Clamp

DIMENSIONS AND SIZING

  • Weight (with rack and fenders) 62lbs
  • Weight Capacity 275lbs
  • Total Length 70”
  • Wheel Base 43”
    • XR Frame Dimensions:
    • Rider Height Range 5'5"-6'4"
    • Handlebar Height 41”
    • Handlebar Reach 22”
    • Maximum Seat Height 40”
    • Minimum Seat Height 33”
    • Stand-Over Height 29.5”
    • Seat Tube 19”
    • ST Frame Dimensions:
    • Rider Height Range 5'-6'2"
    • Handlebar Height 40”
    • Handlebar Reach 18”
    • Maximum Seat Height 38”
    • Minimum Seat Height 31”
    • Stand-over Height 17”
    • Seat Tube 18”

WHAT'S INCLUDED

number

Integrated LED headlight and taillight, operated from the display.

number

Charger and Cable. Only use this authorized charger for the battery

number

LCD TFT display with 2.2" screen. 0-9 levels of PAS and advanced metrics.

number

Schwalbe Super-Moto X Tires eBike touring tires with Green-Guard.

number

Two keys for the removable integrated battery system

number

Heavy duty Kickstand to support the extra weight of an eBike

Shipping Information

*Increased shipping demand nationwide has caused delays in tracking updates from Fedex and delays in shipping hubs. Shipping estimates are slightly delayed beyond the normal timelines.
Delivery time is dependent on your distance from Nevada (our warehouse location). We typically deliver in 2-3 days within the west coast and, or 4-7 days for the east coast.

Bike will arrive 85% assembled (electronics are pre-assembled). An assembly video is located on our support page. Front fork, front tire, seat, pedals, rack and fenders and crank arm need to be installed. Installation can be completed in 1-2 hours. However, it is recommended to use a bike mechanic when possible to check the bike prior to riding. Damages resulting from improper assembly are not covered by the warranty.

Package Size is 52″x30″x8″ and just under 75lbs

FAQ'S

No. We are a direct-to-consumer company both in pricing and strategy. You will generally pay a premium for the ability to test ride. Due to our direct to consumer pricing strategy, we do not have nationwide dealer partnerships. There are some very helpful videos on YouTube reviewing the bike and detailing a closer look.

This article will explain all about what to expect when ordering a bike from us. Ordering With Us

Unfortunately the 14ah battery pack is the largest available that will fit this frame.

No. The variations you see on the site are the only options we have.

We only ship within North America. The Continental United States is FREE. Hawaii and Alaska is $190. Shipping to Mexico and Canada is $100. We are not responsible for any additional tariffs charged by your local government which often times applied after importing. Unfortunately, we are not able to ship our bikes directly to Europe. You can use a shipping forwarder like ShopUsa.com to reach your country.

The bikes are not water-proof, they are water-resistant, rated IP-65. While we do not recommend leaving the bikes out in the rain or riding in the rain or other hazardous conditions due to personal safety, the bikes can handle water exposure.

We’ve summarized some of the pros and cons of each model in this article. https://ride1up.com/which-ebike-is-right-for-you/
